Full bore ball valve 3 piece with Butt Weld ANSI B 16.25. Stainless steel construction 1.4408 (CF8M). Seats PTFE + 15% fiberglass (other material to be consulted). FKM (Viton) shaft O-ring. PTFE steam gasket + 15% graphite. Locking system. Direct mounting actuator according to ISO 5211. Blow-out proof stem. Maximum working pressure: 63 bar. Working temperature: -25ºC +180ºC.
| REFERENCE | SIZE | WEIGHT |
|---|---|---|
| 2026V XX 04 | 1/2" | 0.50 kg |
| 2026V XX 05 | 3/4" | 0.84 kg |
| 2026V XX 06 | 1" | 1.04 kg |
| 2026V XX 07 | 1 1/4" | 1.88 kg |
| 2026V XX 08 | 1 1/2" | 2.55 kg |
| 2026V XX 09 | 2" | 3.70 kg |
| 2026V XX 10 | 2 1/2" | 8.98 kg |
| 2026V XX 11 | 3" | 13.08 kg |
| 2026V XX 12 | 4" | 20.31 kg |
XX=30º/60º/90º.
Control valve with "V" ball 3 pieces
Full bore ball valve 3 piece with Butt Weld ANSI B 16.25. Stainless steel construction 1.4408 (CF8M). Seats PTFE + 15% fiberglass (other material to be consulted). FKM (Viton) shaft O-ring. PTFE steam gasket + 15% graphite. Locking system. Direct mounting actuator according to ISO 5211. Blow-out proof stem. Maximum working pressure: 63 bar. Working temperature: -25ºC +180ºC.
| REFERENCE | SIZE | WEIGHT |
|---|---|---|
| 2026V XX 04 | 1/2" | 0.50 kg |
| 2026V XX 05 | 3/4" | 0.84 kg |
| 2026V XX 06 | 1" | 1.04 kg |
| 2026V XX 07 | 1 1/4" | 1.88 kg |
| 2026V XX 08 | 1 1/2" | 2.55 kg |
| 2026V XX 09 | 2" | 3.70 kg |
| 2026V XX 10 | 2 1/2" | 8.98 kg |
| 2026V XX 11 | 3" | 13.08 kg |
| 2026V XX 12 | 4" | 20.31 kg |
XX=30º/60º/90º.
€67.64
Tax excluded
Delivery 4-5 days except sale
